3. Tool installation

Reminder: You must never forget tab-complete.

Reminder: google is your friend.

3.1. Install the conda package manager

Software packages and tools are pieces of software that have been developed to perform specific jobs, or are used to implement specific methods. Your general view of a software package may be something like Excel or Chrome or TikTok. More fundamentally, software is simply a group of instructions used to perform a specific task. In bioinformatics, for example, this could be a set of instructions telling the computer how to interpret and display the quality scores from a .fastq file.

However, software packages and tools often have dependencies, which are other pieces of software or tools that are necessary to run the software you would like to install. For example, to use Instagram, you also need software that controls your phone’s camera. This reliance of Instagram on camera-controlling software is known as a dependency. Importantly, software like Instagram is designed to be user-friendly, and during installation will usually check that such camera-controlling software exists, and if it does not, may try to install it.

Despite the existence of dependencies, many bioinformatics software programs, much of which is written by inexperienced computer scientists (or worse, biologists) do not check for dependencies. This can create significant issues if you try to run a piece of software but are missing dependencies (the other pieces of software that are also required Fig. 3.1).

../_images/dependencies.jpg

Fig. 3.1 They’re everywhere so we have to be careful.

To make sure that we resolve all these dependency issues, we will use a package/tool managing system. This managing system is called conda, and it is perhaps the most common package manager used in bioinformatics.

The process of installing a software package is called a recipe, and these recipes are contained in places called channels. Most recipes for bioinformatic software is contained in the bioconda channel, which currently has recipes for more than 7000 software packages. conda is not installed by default, thus you need to install it first to be able to use it.

The installation of this tool is perhaps the most complicated installation we will do in this course. However, after the installation of conda, your life will become far easier and you will be on your way to becoming a seasoned bioinformatician (binfie). Note that in the code sample below, you will not be able to use tab-complete because the file does not yet exist on your computer.

# download latest conda installer
wget https://repo.anaconda.com/miniconda/Miniconda3-latest-Linux-x86_64.sh

Explanation: wget is a program that is used to transfer data to or from a server on the command line. Thus, this command is simply using this program to find the file at the location indicated. This file (with the extension .sh) is a bash file, which is usually run using the command line program bash.

Attention

As alluded to previously, noting the extension of a file can be very helpful in figuring out what is in it, or what it does. For example, you should never end a bash file with .txt as that suggests it is a simple text file, when in fact it is not. Similarly, you would never end a Microsoft Word file with .xlsx, you would end it with .doc or .docx

Let’s now actually install conda (in our case we install a miniature version of it with less bloat, miniconda)

# run the installer
# note: now you can use tab-complete
bash Miniconda3-latest-Linux-x86_64.sh

# delete the installer after successful run
rm Miniconda3-latest-Linux-x86_64.sh

Tip

  1. Why should you be careful when using rm in the above command?

Finally, close the shell/terminal and open a new shell/terminal. Now, you should be able to use the conda command. One useful way to check that conda (or most other command line programs) is to ask what the program does. This is almost always done by typing --help or -h after the command. For example try:

conda --help

This will bring up a list of sub-commands that conda can do. Try it.

Finally, make sure you have the current version of conda:

conda update conda

Besides now having conda available as your package manager, one additional thing has changed - your $PATH variable. conda has put the directory ~/miniconda3/bin first on your $PATH variable. (The little ~ (tilde) at the start is short-hand for your home directory.) What is your $PATH variable and why do we need to prepend it with ~/miniconda3/bin? Read on:

The $PATH variable contains places (directories) in which your computer looks for programs. These directories are listed one after the other. The computer will search these in the order they are listed until the program you requested is found (or not, then it will complain). For example, you might have a $PATH variable that says: first look in my home directory (~/), and then in the /usr/bin/ directory, and then in my friend’s directory (/friends_dir/sneaky_software_i_saved_there/). However, those are the only places the computer will look. If you want the computer to look in more places, you have to add those locations to the $PATH variable. The $ indicates that it is a variable.

Through the installation of conda you have now told the computer to also look in ~/miniconda3/bin - so that the program conda can be found anytime you open a new shell, and any program that conda installs will be used first. Thus, conda-installed programs will take precendence over the same programs installed elsewhere.

3.1.1. Configure conda channels to make recipes available

The methods to install different tools are called recipes, and these are stored in what conda calls channels (as noted above). To make sure conda looks in the right places for these recipes, we need to tell it what channels to look in, and in what order to search them. This will make the bioinformatics and genomics tools easily find-able for installation:

# Install some conda channels
# A channel is where conda looks for recipes to install pakcages
conda config --add channels defaults
conda config --add channels bioconda
conda config --add channels conda-forge

3.2. Create environments

Now that we have a method to manage the installation of software packages (the conda package manager), there may be times that we want to have multiple different versions of a software tools installed (e.g. both python 2.7 and python 3.7). In addition, there may be some software tools that conflict with other software tools. This creates a new problem for us. However, we can solve this by creating different conda environments. You can imagine these as independent rooms in a larger conda house. In these rooms (environments), we can install only certain versions of a software tool, or only certain pieces of software. So if you want to have a set of specific software tools for performing QC, you can put those in the QC room (environment), and they will stay in there and not interfere with tools you have installed in other rooms (environments).

# make a new environment with version 3.7 of python
# think of a nifty memorable name
# here we use ngs ("next generation sequencing")
conda create -n ngs python=3.7

# activate the environment
conda activate ngs

So what is happening when you type conda activate ngs in a shell? The $PATH variable (mentioned above) gets temporarily manipulated like so:

# make a new environment with version 3.7 of python
# (we did this in the last code block using the
# conda create command and won't repeat here)

# in the line below the $ indicates that you are
# at the command line prompt
$ conda activate ngs

# Lets look at the content of the $PATH variable
# Note that the command line prompt now has (ngs)
# Note also that we prefix $PATH with a $ as it is a variable
# This is not necessarily your exact path.
(ngs) $ echo $PATH
/home/myusername/miniconda3/envs/ngs/bin:/home/myusername/miniconda3/bin:/usr/local/bin: ...

The colons (:) in the above text indicate separations between the directory listings.

Now it will look first in your specific conda environment’s bin/ directory but afterwards in the general conda bin/ (/home/manager/miniconda3/bin). So basically, everything you install generally with conda (without being in an environment) is also available to you, but gets overshadowed if a similar program is in /home/manager/miniconda3/envs/ngs/bin and you are in the ngs environment.

The huge additional advantage of making separate conda environments in which you do your work is that it makes your work reproducible, as you can easily re-create the entire tool-set with exactly the same software versions numbers later on (e.g. years later, when the functionality of the current software version may have changed completely).

Tip

Extra-credit reading: What are all these bin/ directories, and why are they called “bin”?

3.3. Install software

To install software into the activated environment, use the command conda install.

# install more tools into the environment
conda install cool-new-package

Tip

Does this instruction really mean that you install all packages using the phrase “cool-new-package”?

Note

To tell if you are in the correct conda environment, look at the command-prompt. Do you see the name of the environment in round brackets at the very beginning of the prompt, e.g. (ngs)? If not, activate the ngs environment with conda activate ngs before installing the tools.

3.4. General conda commands

# to search for packages
conda search [package]

# To update all packages
conda update --all --yes

# List all packages installed
conda list [-n env]

# conda list environments
conda env list

# create new env
conda create -n [environment-name] package [package] ...

# activate env
conda activate [environment-name]

# deavtivate env
conda deactivate
